10 Lac / Unit
| Business Type | Manufacturer, Supplier, Trader |
| Wall Panels Material | Electro Galvanized Steel,Stainless Steel |
| Wall Panel Thickness | 1.0 Mm To 1.5 Mm Sheet Thickness |
| Surface Finish | Anti-bacterial Powder Coated Finish |
| Click to view more | |
Product Details
Ceiling Type
Modular Hermetically Sealed Ceiling System
Flooring Type
Conductive PVC Flooring,Antistatic Vinyl Flooring
Flooring Thickness
2 Mm To 3 Mm
Corner Design
Radius Corners For Easy Cleaning And Infection Control
Air Changes Per Hour
20–30 ACH
Clean Room Class
ISO Class 5,Class 100
Positive Pressure Level
5–20 Pascal
Temperature Control Range
18°C To 24°C
Humidity Control Range
40% To 60% RH
- Wall Panels Material: Electro galvanized steel / Stainless steel / HPL compact laminate panels
- Wall Panel Thickness: 1.0 mm to 1.5 mm sheet thickness
- Surface Finish: Anti-bacterial powder coated finish
- Ceiling Type: Modular hermetically sealed ceiling system
- Ceiling Material: GI powder coated / Stainless steel ceiling panels
- Flooring Type: Conductive PVC flooring / Antistatic vinyl flooring
- Flooring Thickness: 2 mm to 3 mm
- Corner Design: Radius corners for easy cleaning and infection control
- Air Flow System: Laminar Air Flow (LAF) system
- Air Changes Per Hour: 20–30 ACH
- HEPA Filter Efficiency: 99.97% at 0.3 micron
- Clean Room Class: ISO Class 5 / Class 100
- Positive Pressure Level: 5–20 Pascal
- Temperature Control Range: 18°C to 24°C
- Humidity Control Range: 40% to 60% RH
- Noise Level: Less than 55 dB
- OT Door Type: Automatic sliding hermetic door / Hinged hermetic door
- Door Material: Stainless steel / Powder coated steel
- Door Operation: Sensor based automatic operation
- Viewing Window: Double glazed flush mounted glass
- OT Light Type: LED Shadowless OT Light
- Illumination Intensity: 1,20,000 to 1,60,000 Lux
- Color Temperature: 3500K–5000K adjustable
- Pendant Type: Single arm / Double arm surgical pendant
- Medical Gas Pipeline System: Oxygen, Nitrous Oxide, Vacuum, Air outlets
- Electrical System: Isolated power supply system
- Control Panel Features: Touch screen control panel with alarm indicators
